SY8303 TSOT23-8
矽力杰 SY8303A TSOT23-8 DC-DC同步降壓
主要應用領域：
引腳兼容型號：
SY8303.PDF
SY8303A.PDF
SY8303 內置MOS 40V/3A同步降壓轉換器
概述：
The SY8303 develops a high efficiency synch step-down DC-DC converter capable of delivering 3A load current. The SY8303 operates over a wide input voltage range from 4.5v to 40V and integrates main switch and synchronous switch with very low Rps(oN) to minimize the conduction loss
The SY8303 adopts peak current control scheme. The switching frequency is adjustable from 500kHz to 2.5MHz using an external resistor. The device also eatures ultra low quiescent operating to achieve high efficiency under light load. And the internal soft-start limits inrush current during power on
SY8303 is available in TSOT23-8 package
特性：
Low RDs(oN) for internal switches(top/bottom) 110/70mg
4.5-40V input voltage range
Internal compensation
Internal lms soft-start limits the inrush current
Adjustable switching frequency range: 500kHz to 2. 5MHZ
3A output current capability
1.5% 0.6V reference
Low quiescent current
Cycle-by-cycle peak current limitation
Short circuit protection
Thermal shutdown and auto recovery
RoHS Compliant and Halogen Free
Compact package: TSOT23-8
典型應用：
